How I structure Terraform configurations? [archived]

Note that this blog post was originally written in September 2016, and many things has been changed since then.

In this blog post I want to describe one of the ways I like to structure
Terraform configurations which can be used to manage medium and large
infrastructures with resources span multiple AWS accounts (for eg,
development, staging, production) and multiple regions.

Here I follow so called "layered infrastructure principle".

There was very interesting talk about running Terraform At Scale by
Calvin French-Owen (Co-Founder and CTO at Segment) at HashiConf 2016,
where he was describing same types of challenges I was solving in my setup.

Infrastructure review:

Resources are grouped into layers, where each layer consists only of:

• global resources (IAM, Cloudfront, Cloudtrail, Config, Route53 zones)
• or regional resources (EC2, VPC, Codedeploy, Cloudformation)

Developer can interact with a single layer, which is identifiable by combination of arguments:

• AWS account alias (company-dev, for example)
• Region name (eu-west-1, for example)
• Layer name (global, shared, application, for example)

Directory structure:

.
├── accounts
│   ├── company-dev
│   │   ├── application.eu-west-1.tfvars
│   │   ├── global.tfvars
│   │   └── shared.eu-west-1.tfvars
│   ├── company-cicd
│   │   ├── cicd.eu-west-1.tfvars
│   │   └── global.tfvars
│   ├── company-legacy
│   │   └── legacy.tfvars
│   ├── company-prod
│   │   ├── application.eu-west-1.tfvars
│   │   ├── global.tfvars
│   │   └── shared.eu-west-1.tfvars
│   └── company-staging
│       ├── application.eu-west-1.tfvars
│       ├── global.tfvars
│       └── shared.eu-west-1.tfvars
├── layers
│   ├── company-dev
│   │   ├── application
│   │   │   ├── main.tf
│   │   │   ├── output.tf
│   │   │   └── variables.tf
│   │   ├── global
│   │   │   ├── main.tf
│   │   │   ├── output.tf
│   │   │   └── variables.tf
│   │   └── shared
│   │       ├── main.tf
│   │       ├── output.tf
│   │       └── variables.tf
│   ├── company-infra
│   │   ├── cicd
│   │   │   ├── iam.tf
│   │   │   ├── main.tf
│   │   │   ├── output.tf
│   │   │   └── variables.tf
│   │   └── global -> ../../company-dev/global
│   ├── company-static
│   │   └── static
│   │       ├── main.tf
│   │       ├── output.tf
│   │       └── variables.tf
│   ├── company-prod
│   │   ├── application -> ../../company-staging/application
│   │   ├── global -> ../../company-staging/global
│   │   └── shared -> ../../company-staging/shared
│   └── company-staging
│       ├── application
│       │   ├── main.tf
│       │   ├── output.tf
│       │   └── variables.tf
│       ├── global
│       │   ├── main.tf
│       │   ├── output.tf
│       │   └── variables.tf
│       └── shared
│           ├── main.tf
│           ├── output.tf
│           └── variables.tf
├── modules
│   ├── application
│   │   ├── codedeploy.tf
│   │   ├── output.tf
│   │   └── variables.tf
│   ├── global
│   │   ├── cloudtrail.tf
│   │   ├── iam.tf
│   │   ├── main.tf
│   │   ├── output.tf
│   │   └── variables.tf
│   ├── shared
│   │   ├── bastion.tf
│   │   ├── networking.tf
│   │   ├── output.tf
│   │   ├── route53.tf
│   │   ├── variables.tf
│   │   └── vpc_peering.tf
│   └── typical_service
│       ├── codedeploy.tf
│       ├── output.tf
│       ├── service.tf
│       └── variables.tf
└── terraform.sh

Notes:

• accounts/{aws_alias}/*.tfvars - values
• layers/{aws_alias}/{layer_name}/*.tf - Terraform configurations. Normally it contains module invocations and terraform_remote_state configurations to higher layers (global and shared).
• layers/company-prod/* - is a symlink to layers/company-staging/* to reduce chance of configuration drift
• modules - Terraform modules (typically invoked from multiple AWS accounts with various values)
• terraform.sh - Terraform wrapper script (or Terragrunt), which sets correct working directory and load correct tfvars file

Pros:

• Easy to navigate infrastructure as code
• Outputs of higher level layers are available as read-only values to layers below
• Full set of Terraform features (commands and arguments) is supported
• Versioned layers based on same tfvars can be implemented (A/B testing, blue-green deployment)
• Very easy to integrate with CI pipeline
• Locking is implemented using Terragrunt

Cons:

• May be hard to limit permissions for Terraform users between state files inside one AWS account (all states files are readable by users in that account, by default)
